YCQ1B Automatic Transfer Switch

4,650.00৳

Product parameters:

Type YCQ1B-63
Working frequency 50Hz/60Hz
Rated voltage AC400V
Operating Voltage AC220V
Standards compliant IEC60947-6-1
Product Size 185mm×138mm×115mm
Operation method Automatic and manual
ATS level CB
Conversion time ≤2s
Current specifications 10A-63A
Conversion method Self-return
Category:

Description

Product Overview

The dual power automatic switch is used to switch between two power sources. It is divided into common power supply and standby power supply. When the common power supply is powered off, the standby power supply is used. When the common power supply is called, the common power supply is restored), if you do not need automatic switching in special circumstances, you can also set it to manual switching (this type of manual / automatic dual-use, arbitrary adjustment).
